Formfutura Dental LCD Series - Model Resin 500ml

Référence formfutura_modelresin Marque Formfutura

Formfutura Dental LCD Model Resin est une résine photopolymère de haute précision conçue pour la modélisation précise des modèles dentaires, des modèles d'aligneurs, des gencives, des dents, des modèles de couronne et de bridge avec matrices amovibles. Le modèle LCD dentaire est spécialement conçu pour fonctionner avec toutes les imprimantes 3D LCD et DLP open source dans la plage de 385 à 420 nm.
La résine modèle LCD dentaire a une finition de surface et une couleur similaires à celles du gypse, ce qui accentue parfaitement la profondeur et les détails du modèle dentaire. La résine modèle Formfutura Dental LCD est destinée à des fins de modélisation uniquement et non à une utilisation intra-orale.

49,95 €
49,95 € TVAC 41,28 € HTVA

Formfutura Dental LCD Series - Model Resin 500ml

Key features

  • High-resolution 3D printing with fine detail

  • Almost Odorless processing

  • Excellent dimensional accuracy and low shrinkage

  • Gypsum-like texture and color

  • Temperature resistant for dental aligner production

  • Compatible with all open source LCD and DLP 3D printers in the range of 385 - 420nm


  • Models of dentures

  • Implant models

  • Crown and bridge models

  • Models of gums

  • Orthodontic models

Resin properties (uncured liquid)

  • Viscosity: 700 cps at 25°C

  • Density: 1.18 g/cm2

Mechanical properties

Test method on post cured objects through 30 minutes high power LED curing.



Typical Value

Test Method

Glass transition temperature (Tg)


ASTM D7028

Water absorption


ASTM D570-98

Impact strength (IZOD notched)

17 J/m


Tensile strength

46 MPa


Tensile Modulus

1100 MPa


Elongation at break



Flexural Strength

68 MPa


Flexural Modulus

1900 MPa

ASTM D2240

Shore D Hardness


ASTM D2240

Please note that the above-displayed values can vary with individual machine processing, post-curing parts,  geometry, print orientation, print settings, and temperature.

Preparation(s) before starting to print

  • Shake the bottle for at least 2 minutes before each use.

  • After shaking the bottle, leave the resin to rest for 10 minutes to let air bubbles get out of the resin

    • The resin can be poured back from the vat into the bottle once your print is finished

  • Always use protective measurements like safety glasses and nitrile gloves when handling resins.

General printing guidelines

  • Burn-in layers: 2x  170 sec

  • Base layer curing times at 50 microns:  ±14 - 17 sec


  • We do advise you to post-process your 3D print in order to achieve the material properties

    • Rinse your 3D printed object in IPA or (Bio)Ethanol for approximately 5 minutes

  • An ultrasonic cleaner is preferred/recommended

    • Make sure that IPA and/or (Bio)Ethanol rinsed objects are perfectly dry before further post-curing

  • Place the rinsed parts in a well-ventilated area for at least 30 minutes, or use pressurized air for at least 2 minutes

    • Cure your object in a high power curing chamber for approximately 20-30 minutes at 65° C

  • The preferred curing wavelength is between 300-410nm


Please always be aware that when 3D printing with resins that you are working with chemicals and that you should always be cautious and use the personal protective equipment as stipulated in our safety data sheets.

  • Always wear Respiratory Protection when sanding/cutting the resin object.

  • Always use nitrile gloves when handling resins and uncured resin objects.

Product export information

HS Code: 2916140090 Description: Resin for 3D Printing Country of origin: the Netherlands
