Formfutura Platinum LCD Series - Translucent black 500ml

Référence formfutura_stdresin Marque Formfutura

La série LCD Formfutura Platinum est une résine LCD photopolymère à usage général spécialement développée pour fonctionner avec toutes les imprimantes 3D LCD et DLP open source dans la plage de 385 à 420 nm. Notre résine LCD Platinum est presque inodore et imprime en 3D avec une précision extrêmement élevée et une finition de surface très lisse. La série Platinum LCD Resin est développée pour imprimer en 3D avec des temps de séchage relativement courts.

42,50 €
42,50 € TVAC 35,12 € HTVA

Formfutura Platinum LCD Series - Translucent black 500ml

Key features

  • Almost no odour  - Compared to other resins on the market our Platinum LCD resin is relatively odour-free!

  • UV & weather resistant

  • Fast printing with short curing times

  • High-resolution 3D printing with fine detail

  • Vivid colors with an extremely high level of colorfastness

    • Truly opaque and translucent colors available

    • No discoloration and/or yellowing

  • Excellent dimensional accuracy and low shrinkage

  • Low water absorption

  • Compatible with all open source LCD and DLP in the range of 385 - 420nm


  • Figurines and models

  • Functional prototyping

  • End-use products

Resin properties (uncured liquid)

  • Viscosity: 500 cps at 25°C

  • Density: 1.18 g/cm2

Mechanical properties

Test method on post cured objects through 10 minutes high power mercury curing.



Typical Value

Test Method

Glass transition temperature (Tg)


ASTM D7028

Water absorption


ASTM D570-98

Impact strength (IZOD notched)

18 J/m


Tensile strength

45 MPa


Tensile Modulus

1000 MPa


Elongation at break



Flexural Strength

66 MPa


Flexural Modulus

1800 MPa

ASTM D2240

Shore D Hardness


ASTM D2240


Please note that the above-displayed values can vary with individual machine processing, post-curing parts,  geometry, print orientation, print settings, and temperature.

Preparation(s) before starting to print

  • Shake the bottle for at least 2 minutes before each use.

  • After shaking the bottle, leave the resin to rest for 10 minutes to let air bubbles get out of the resin

    • The resin can be poured back from the vat into the bottle once your print is finished

  • Always use protective measurements like safety glasses and nitrile gloves when handling resins.

General printing guidelines

Base Curing Times at 50 micron

  • Translucent Black: 12sec

  • Translucent Aquamarine: 10sec

  • Translucent Blue: 12sec

  • Translucent Red: 11sec

  • Solid White: 12sec

  • Solid Black: 14sec

  • Solid Light Grey: 13sec


  • We do advise you to post-process your 3D print in order to achieve the material properties

    • Rinse your 3D printed object in IPA or (Bio)Ethanol for approximately 5 minutes

  • An ultrasonic cleaner is preferred/recommended

    • Make sure that IPA and/or (Bio)Ethanol rinsed objects are perfectly dry before further post-curing

  • Place the rinsed parts in a well-ventilated area for at least 30 minutes, or use pressurized air for at least 2 minutes

    • Cure your object in a high power curing chamber for approximately 20-30 minutes at 65° C

  • The preferred curing wavelength is between 300-410nm


Please always be aware that when 3D printing with resins that you are working with chemicals and that you should always be cautious and use the personal protective equipment as stipulated in our safety data sheets.

  • Always wear Respiratory Protection when sanding/cutting the resin object.

  • Always use nitrile gloves when handling resins and uncured resin objects.

Product export information

HS Code: 2916140090 Description: Resin for 3D Printing Country of origin: the Netherlands
